                  Ultra-Slim LED Strip Light
                  • Ultra-Slim LED Strip LightUltra-Slim LED Strip Light

                  Ultra-Slim LED Strip Light

                  Jingzhao Lighting leads the industry in crafting Ultra-Slim LED Strip Lights. These sleek and compact lights offer a discreet yet powerful lighting solution for various applications. Engineered with precision and innovation, our ultra-slim LED strip lights deliver exceptional brightness while maintaining a slim profile. Trusted by customers for their versatility and space-saving design, Jingzhao Lighting's LED strip lights redefine the possibilities of modern illumination.

                  Send Inquiry

                  Product Description

                  The Jingzhao Lighting manufacturer's ultra-slim LED strip light is a lighting fixture that consists of a thin, flexible strip embedded with light-emitting diodes (LEDs). These strips are designed to provide illumination in a variety of settings, from accent lighting in homes and businesses to decorative lighting in vehicles and outdoor spaces.The ultra-slim design makes these LED strip lights highly flexible, allowing them to be installed in tight spaces and around curves. This flexibility makes them suitable for a wide range of applications.



                  FEATURE


                  • Rigid light bar series using rigid base material in FR4 and aluminum, for case requiring structural installation method using screw, clip and so on. Classical constant voltage design support on-filed flexible cutting and connection into certain length. Various of features can be achieved and selected, such as top-view, side-view, ultra-slim, high-density.

                  • 50,000h long lifespan.



                  2835 LED Top-View


                  LLED Qty

                   Increment

                  Part No.

                  Voltage

                  Power

                  Brightness

                  @4000K&CRI80

                  Dimension

                  @IP20

                  PCB Type

                  70LED/M

                  (21LED/ft.)

                  100mm

                  (3.94in)

                  EP-24-R039

                  (EP-R2835XX-24-CV-070-R039)

                  24VDC

                  7.2W/M

                  (2.2W/ft.)

                  Energy

                  Efficiency

                  Class

                  760lm/M

                  (230lm/ft.)

                  L1200*W8*H2mm

                  (L47.2 *W0.32*H0.08in)

                  FR4 Double-Sided /Aluminum Single-Sided

                  140LED/M

                  (42LED/ft.)

                  50mm

                  (1.97in)

                  EP-24-R041

                  (EP-R2835XX-24-CV-140-R041)

                  24VDC

                  14.4W/M

                  (4.39W/ft.)

                  Energy

                  Efficiency

                  Class

                  1520lm/M

                  (460lm/ft.)

                  L1200*W8*H2mm

                  (L47.2 *W0.32*H0.08in)

                  FR4 Double-Sided /Aluminum Single-Sided

                  238LED/M

                  (72LED/ft.)

                  29.4mm

                  (1.16in)

                  EP-24-R026

                  (EP-R2835XX-24-CV-238-R026)

                  24VDC

                  16.32W/M

                  (4.98W/ft.)

                  Energy

                  Efficiency

                  Class

                  1700lm/M

                  (520lm/ft.)

                  L1200*W10*H2mm

                  (L47.2 *W0.4 *H0.08in)

                   FR4 Double-Sided /Aluminum Single-Sided



                  2835 LED Ultra-Slim


                  LED Qty

                  Increment

                  Part No.

                  Voltage

                  Power

                  Brightness

                  @4000K&CRI80

                  Dimension

                  @IP20

                  PCB Type

                  70LED/M

                  (21LED/ft.)

                  100mm

                  (3.94in)

                  EP-24-R040

                  (EP-R2835XX-24-CV-070-R040)

                  24VDC

                  7.2W/M

                  (2.2W/ft.)

                  760lm/M

                  (230lm/ft.)

                  L1200*W4*H1.8mm

                  (L47.2*W0.16*H0.07in)

                  FR4 Double-Sided

                  140LED/M

                  (42LED/ft.)

                  50mm

                  (1.97in)

                  EP-24-R028

                  (EP-R2835XX-24-CV-140-R028)

                  24VDC

                  14.4W/M

                  (4.39W/ft.)

                  1520lm/M

                  (360lm/ft.)

                  L1200*W4*H1.8mm

                  (L47.2*W0.16*H0.07in)

                  FR4 Double-Sided



                  Transport of Goods


                  Zhongshan as an important city in the Pearl River Delta region, the logistics routes are four and five, basically all over every corner of the country, if you do not have a designated logistics company, we will choose the appropriate special line to deliver to you according to your delivery address, reduce your logistics costs.
